Model:ET150MR
ET150MR Semi-auto pallet wrapper
Compare with ET100MR, this machine have PLC controller, this allow ET150MR friendly to operate. The operator can choose different wrap cycle and Top/Bottom wraps from the panel.
The high quality of components used ensure the high quality.
Technical Data
Max load size(mm)
Max load height(mm)
Capacity: 20-30 Loads/hr based on load
Turntable diameter
Turntable Height
Turntable weight capacity
Turntable speed 3-12rpm
Machine weight
Electrics 220V 50HZ 1Phase
Power 1.2kw
Machine dimensions (mm) 2625(L)*1650(W)*2895(H)
Specification
Control Panel: Top/Bottom 1-3 wraps, Wrap cycle 1-3, Start,
Reset/Pause, E/S button, Main switch
Manual: Carriage up, Carriage down, Turntable Jog,
OMRON PLC
Photo-eye pallet height sensor
Film carriage with Mechanical brake (variable film tension control )
3—12RPM variable turntable speed by inverter
Turntable soft start/soft stop, heavy duty chain drive
Variable carriage up/down speed
Safety stop to avoid foot crush
Hinged mast for easy handling
Front & rear Forklift transportable
Option
Ramp
Pneumatic top plate
Packing height :
Turntable diameter :
Turntable capacity: 2500kgs, 3000kgs
Machine Color
