ZT9802 TUBER

 ZT9802-Tuber Making Machine 2-5 layers of paper machine can produce flat pocket cylinders, cylinders and bags trapezoidal bottom of the wall kits cylinders, the 12-part structure.



The Technical data:

Tube length:650-1050mm

tube width:400-620mm

Double or four colors printing

Printing Wide:0-1300mm

Output:160 tubes/min

(Can perforate anywhere & add PE to any ply)

Size of whole set;

LxWxH:34mX2.4mX2.7m

Total weight:34 tons

Power efficency:25KW



R: release volumes, automatic device, the delivery system of paper and stratification orientation, automatic release. Correct parts, auxiliary drive, gill Kong, horizontal ladder points plastic, vertical distribution associate toilet lines and bags cylinders Shijiao card, bags cylinder shape, drive and anger, separation send kits - server functions, bags cylinders counting, sorting transmission and sub-stall innovative release, since programmed control electrical systems.
