Model:-
Send Inquiry
1.With seiko SPT510/35pl printhead, 4,6,8 heads on the printer.
2.Printing width 3.2m.
3.Resolution 720dpi max.
| Print Technology | Drop on demand Piezo Head(SEIKO/SPT510) | ||
| Print Head | 8Heads (Seiko/Spt 510) | 6Heads (Seiko/Spt 510) | 4 Heads (Seiko/Spt 510) |
| Print Width | 3.2m width | ||
| Resolution | 720dpi Max | ||
| Speed | 2 Pass 101 m2/h | 2 Pass 56 m2/h | 2 Pass 56 m2/h |
| 3 Pass 96 m2/h | 3 Pass 48 m2/h | 3 Pass 48 m2/h | |
| 4 Pass 74 m2/h | 4 Pass 36 m2/h | 4 Pass 36 m2/h | |
| 6 Pass 50 m2/h | 6 Pass 24 m2/h | 6 Pass 24 m2/h | |
| 8 Pass 30 m2/h | 8 Pass 16 m2/h | 8 Pass 16 m2/h | |
| Locating Mode | Raster strip/Raster sensor | ||
| Media Width | 3.3m | ||
| Color | C M Y K LC LM | ||
| Ink Type | Special ink for Seiko Print Head | ||
| Ink | Solvent based Pigment Ink, At least tow years outdoor | ||
| Ink delivery system | Ink force pumps auto supplying system , Main ink case 1L/color | ||
| Media Handle | Roll to Roll handling | ||
| Media feeding &take-up system | Infra Red Optical Controlling System for Media Feeding &Take-up | ||
| Dry system | Pre/Post and Middle heater controlled by PID | ||
| Media Type | PVC Vinyl, Flex banner, Carpet Paper, PVC Mesh Fabric, Perforated Vinyl, Cloth Banner Etc. | ||
| Motor | Step Motor | ||
| Linear Rail | THK / HLWIN | ||
| Height of Print-head | 1mm -10mm above media, Adjustable | ||
| Print head maintenance facility | Protection trays for auto purge, daily maintenance and print heads over night | ||
| Auto-cleaning system | Double functional cleaning System of Pressure purge and Vacuum Suction | ||
| Interface | USB2.0 | ||
| Print Mode | Bidirectional Printing | ||
| File Format | TIFF , JPEG , Postscript 3 , EPS , PDFRGB/CMYK | ||
| RIP Software | Original Maintop/Photoprint Rip software | ||
| Working Process | Maintop software, Photoprint software for Windows 98 and Windows XP Etc. | ||
| Power Supply | 50HZ/60HZ, 220V(?0%)>15A | ||
| Filtration Facility | PALL filter + Regular ink filter | ||
| Operation Environment | Temperature: 23~29 Degrees ; Humidity: 50%~80% | ||
| Dimension | 4.6m*0.7m*1.4m | ||
| Weight: | 670kg | ||
