Model:C916
C916 Small Loader With CE
QUOTATION:
Price:12,800.00USD per unit FOB Qingdao,China port.
Warrantee:1200hours or 12monthes which comes first.
Equipment details:
Xinchai A498BT1 EIII diesel engine,Full hydraulic control 4 wheels driving,Hydraulic Quick Hitch with 0.8Cbm bucket,single lever pilot control,Luxury cabin with radio player and warmer/fan,Front and rear/top working light,reverse buzzle,14-17.5 tyres.
CE approved
Optional Attachments/Parts | ||||||||
Model | Pallet fork | Grass fork | Wood grapple | Snow shovel | Fops/rops Cbin | 4 in1 bucket | sleeve bucket | U.S Cummins |
C915 | $680 | $950 | $1,050 | $1,430 | $600 | $1,050 | $670 | $4200 |
Model | Pilot control | Air conditioner | Hydraulic quick hitch | 12.00-16.5 wide tyre | 14-17.5 wide tyre | Snow blower |
|
|
C915 | include | $750 | include | reduce$500 | include | $1850 |
|
|
C915 Specifications
Rated load(kgs) | 1600 |
Bucket capacity(m3) | 0.8cbm |
Unload height (mm) | 2645 this is Dumping height |
Unloading Clearance (mm) | 976 |
Max tractiv force (kN) | 45 |
Operating weight (kgs) | 3600+200kg |
Turning Angle( °) | 30 |
Mini Turning Radius (mm) | 4283 |
Ground Clearance(mm ) | 270 |
Engine | XINCHAI EURO III, A498BT, diesel, 4 cylinders, direct injection,38 kW/2400rpm, displacement2.54l.OPTION US Cummins engine |
Transmission |
|
Hydrostatic transmision | 4WD Fully hydraulic drive,2 gear hydraulic variable speed changes,F2/R2 .AUTOMATIC. torque convert and gearbox assembly are same. |
Speed |
|
Forward I | 0 –7 km/h |
Forward II | 0 –20 km/h |
Reverse I | 0 –7 km/h |
Reverse II | 0 –20 km/h |
Working Hydraulic Pressure | 22 Mpa |
Lifting time (s) | 4.5 |
Tyres | 14.0-17.5 HD |
Dimensions(mm) | 4850x1650x2800 |
Tipping load (ISO/DIS 14397-1), | 3 500mm straight, 1500kgs |
