Model:SJ50-150
Send Inquiry
PPR Single screw extruder for PPR pipe
Application:
It is the best choice of PE, HDPE, PPR pipe production line, film and hard plastic pelletizing line.
Main Technical Parameters:
| Model No. | L/D | Output(kg/h) | Screw Speed(r/min) | Motor power(KW) | Center height(mm) |
| SJ25 | 25/1 | 5 | 20-120 | 2.2 | 1000 |
| SJ30 | 25/1 | 10 | 20-180 | 5.5 | 1000 |
| SJ45 | 25-33/1 | 50-150 | 20-150 | 7.5-22 | 1000 |
| SJ65 | 25-33/1 | 60-250 | 20-150 | 22-90 | 1000 |
| SJ75 | 25-33/1 | 200-350 | 20-150 | 55-110 | 1100 |
| SJ90 | 25-33/1 | 280-550 | 20-110 | 37-185 | 1000-1100 |
| SJ120 | 25-33/1 | 320-880 | 20-90 | 75-280 | 1000-1250 |
| SJ150 | 25-33/1 | 400-1200 | 20-75 | 90-355 | 1000 |
