Available in Nominal Retention Ratings of 1, 7.5 and 10 Microns

Unique Patent Pending Process
Polyester Layers in the 1um Cartridges Provide Additional Strength and Dirt Holding Capacity Excellent Polishing Filter for Process or Closed-loop Streams
Manufactured with FDA Listed Components
DOE End Configuration with end caps

Product Specifications
Retention Ratings: 1, 7.5, 10 um
Recommended Flow Rates: 5 gpm (19 lpm) for 10inch
Maximum Temperature: 40º F to 125º F(4.4º Cto 52º C)
Materials of Construction: Filter Media: Activated Carbon Fibers Impregnated Cellulose
Endcaps: Polypropylene

Inner/Outer Wraps: Cellulose Reinforcement Backing/Polyethylene Outer Netting (White netting for 10 micron, Yellow netting for 7.5 micron, and blue netting for 1 micron)

Gaskets/O-rings*: Buna N
Dimensions (nominal):
Outside Diameter: 66mm
Inside Diameter: 28mm
Lengths: 250mm, 508mm
Packaging: 30pcs/ctn
