Price:Negotiable
Model:1625

Send Inquiry

Detailed inforamtion for CNC bending machineTechnical parameters:

Material thickness:	0.3-1.5mm
Material width	2.-180mm
Letter range	80mm and more
Max power	1.5kw
Machine size	2380*1200*1600mm
Weight	380kg
Power	AC 220V/50HZ
Air compressor	0.8Mpa
Precision	0.05mm
Use power	1kw
Feed speed	10-14m/min
document format	Plt

 Product features:1.      Work with serve motor to promise high speed and high precision, feed precision can reach to 0.05mm2.      Auto feeding, auto V-grooving, auto bending and auto cutting.3.      It can work with DXF format vector diagram and it is the same with cnc router software.4.      Using the most advanced imported alloy knife to finish the groove on the stainless steal and aluminum materials.5.      Using two knives change to bend to minimize the angle, it is the most advanced machine in domestic market. Applicable Materials:Different light metal materials and the side bending thickness is 0.3-1.5mm
