Product Description

This machine is used to plane the V-slot on the stainless sheet, aluminum alloy sheet, steel-aluminum compound sheet and other sheet to obtain the smaller inner radius of the workpiece to be bent. It is suitable to decorating, making door & window made of metal material and etc.


Model VBK600 x 4000
Max. Length to be Slotted 3900 mm
Max. Width to be Slotted 600 mm
Max. Thickness to be Slotted 2 mm
Motor Power for Adiusting knife Holder 0.85 kw
Motor Power for Track 2 kw
Motor Power for Slotting 1.5 kw
Size 5350x1450x1720 mm
Weight 5500 kg
