Bench Lathe
2016-11-03 14:13  Views:184
Price:Negotiable
Model:CJ0618
Send Inquiry

1. Distance between centers300mm
2. Swing over bed180mm
3. Swing over cross slide110mm
4. Spindle taperMT3
5. Tailstock taperMT2
6. Chuck diameter80mm
7. Spindle bore20mm
8. Cross slide travel65mm
9. Tool slide travel35mm
10.Range of metric threads0.5-2.5mm
11.Range of imperial threads12-52TPI
12.Spindle accuracy0.01mm
13.Spindle speed100-2500RPM
14.Power of motor400W/550W
15.Vol./Freq.230V/50Hz or 120V/60Hz
16.Net weight35kg/38kg/40kg
17.Gross weight38kg/42kg/45kg
18.Packing size660/760/810x305X315mm
