Model:-
Flotation Machine applies to separation of non-ferrous metal, ferrous metal, noble metal, non-metallic mine, chemical material. And it can be used in roughing, scavenging, selection or reverse flotation.
During the flotation process, pulp will be mixed with drug firstly and agitated. Then target ore grains will selectively attach to bubbles, float onto the surface of pulp, which will be scraped out and collected. And the rest materials will be left there. Thus, the result of separation is accomplished.
Flotation Machine Features:
1. Large inhaling capacity and low energy consumption;
2. Complete flotation circuit with inhaling air and pulp, no auxiliaries are needed;
3. Process is easy to be changed;
4. Reasonable circulation of pulp decreases coarse sand sedimentation;
5. Automatic controlling device makes adjustment more convenient.
SF series Flotation Machine
| Model | SF0.37 | SF0.7 | SF1.2 | SF2.8 | SF4 | |
| Volume (m3) | 0.37 | 0.7 | 1.2 | 2.8 | 4 | |
| Impeller Diameter (mm) | 300 | 350 | 450 | 550 | 650 | |
| Capacity (m3/min) | 0.2-0.4 | 0.3-0.9 | 0.6-1.2 | 1.5-3.5 | 0.5-4 | |
| Impeller speed (r/min) | 352 | 400 | 312 | 268 | 238 | |
| Impeller motor | Model | Y90L-4 | Y100L2-4 | Y132M2-6 | Y160L-6 | Y180L-6 |
| Power (kw) | 1.5 | 3 | 5.5 | 11 | 15 | |
| Scraper motor | Model | Y90S-4 | Y90S-4 | Y90S-4 | Y90S-4 | Y90S-4 |
| Power (kw) | 1.1 | 1.1 | 1.1 | 1.1 | 1.5 | |
