Cutter grinder
2016-11-03 14:24 Views:276
Price:Negotiable
Model:GD-20
Send Inquiry
| Engraving cutter grinder(GD-20) Type GD-20 cutter sharpener is applicable to grind milling cutter of all kinds of diameter, shapers and angles for die sinker, also to die pin corresponding to the miller according to die sinker scale, it has ability of grinding turning tool,drill. So it is an necessary equipment in using die sinker with excellent figuration, new structure and good application.
Specifications | Cup wheel diameter-thickness-bore | 4" x 2" x 3/4" | | Spindle speed | 5200 rpm
| | Collet capacity | 1/8" to 5/8" | | Longitudinal traverse of index head carrier | 5-1/2"
| | Fine longitudinal adjustment travel of index head carrier | 3/4"
| | Taper angle | 0 to 180 degrees
| | Negative taper angle | 0 to 52 degrees | | Relief angle | 0 to 44 degrees | | Motor | 1/4hp, 3400 rpm | | Power | 220V/110V, single phase | | Net weight | 60kg | | Overall dimensions | 48x39x36.5 cm/18" x 14" x 14"
| | Collets | 1/8". 3/16", 1/4", 5/16", 3/8" 1/2", 5/8"
| | Stone wheel | 4" x 2" x 3/4" | | Optional diamond wheel | 4" x 2" x 5/8" |
|
