Model:LD Model
Overhead Cranes
1- LD Single Girder type
2- Lifting capacity: 0.5- 32t
3- Lifting Height: 3-60m
4- Span: 6-34m
Overhead Cranes
LD Single Girder EOT Crane match with the CD1/MD1 type Electric wire rope hoist.
which is the most popular use crane machinery on the market at present.
it is suitable for hoisting, handing and transporting weights in machine shops and stores, etc.
Operation: floor control, cab control.
Crane Travelling Device | Travelling speed (m/min) | 20 | 30 | 45 | 60 | 75 | |
Reducer ratio | 58.95 | 39.42 | 26.38 | 19.37 | 15.88 | ||
Motor | Model | ZDY21-4 | ZDR12-4 | ||||
Power (kw) | 2x0.8 | 2x1.5 | |||||
Rotation (r/min) | 1380 | ||||||
Lifting device (Electric hoist) And hoist travelling device | Electric Hoist model | CD1/ MD1 | |||||
Lifting speed (m/min) | 8, 0.8/8 | ||||||
Lifting height (m) | 6, 9, 12, 18, 24, 30 | ||||||
Travelling speed (m/min) | 20; (30) | ||||||
Motor | Taper Squirrel-cage type | ||||||
Work duty | A3- A5 | ||||||
Power supply | 380V, 50Hz, 3-Phase | ||||||
Wheel Diameter | 270mm | ||||||
Rail Surface width | 37- 70mm | ||||||
