XK7136B,XK7136C,XK7130A

*Sevro-driving system.

*Integrity base.

*Used for high precision and efficient automatic machining of small workpieces.

Specification  XK7136B  XK7136C  XK7130A

X-axis travel  900mm     900mm    460mm

Y-axis travel  360mm     360mm    210mm

Z-axis travel   460mm    460mm    360mm

Spindle nose to table 130-590mm  130-590mm 120-480mm

spindle center to colum guide-way face 450mm   460mm 200-500mm

High speed feeding of X,Y  axis 4000mm/min  4000mm/min 3000

High speed feeding of Z axis    3000mm/min  3000mm/min 3000

Feeding speed       1-2000mm/min    1-2000mm/min   1-2000

Size of working table  1250x360mm      1250x360mm   1000x280

Max. loading capacity of rotary table  400kg   400kg      150kg

T-slot no./width/distance of rotary table   3/18/80mm   3/18/80mm

Spindle speed range/step   76-6980rpm/20steps  200-4000rpm/min 66-4540

Main motor power        3.7kw          5.5.kw   2.2kw

Spindle taper            7:24 ISO40     BT40     7:24 ISO30

Positioning accuracy of x/y/z axis 0.04mm   0.04       0.04

Re-positioning accuracy of x/y/z axis 0.02mm  0.002    0.025

Overall dimension  2220x1850x2350mm    2220x1850X2350  1560x1340X2130

N.W.         2200kg                 2200KGS   1300
