Grease pump with barrel 68213 Description:

Grease pump with barrel 68213 is a mobile grease pump with 13kg wheel-mounted tank. It is always ready for use and enables easy greasing at high pressure on any motor vehicle or machinery. The seamless pressed tank offers maximum guarantee of adherence and functionality of follower plate.

It is an air supply device and controlled by pneumatic component which is steady, effective and widely supplied.

Grease pump with barrel 68213 equipped with:

- air-operated pump for grease, ratio 50:1

- nipples connection

- turnable grease gun

- delivery hose 1/ 4 inch and 4 m length

- follower plate which can be applied to a standard drum, if there is an anomalistic one you should illuminate other way.

Grease pump with barrel 68213 Technique data:

Tank capacity:           13KG
Pump raito:              50:1
Free Flow Rate:          500-900g/min

Connecting Hose:         4m Length, 1/4" inner dia.
Air pressure:            4-8Kg/cm2
Delivery pressure:        480 Kg/cm2

Air Inlet Connection:     1/4"

Grease Outlet Connection: 1/4"

Air Consumption:          3-8 bar

Net weight:               16.0 Kgs
Gross weight:            18 Kgs

Dimensions:               330x330x820mm

Grease pump with barrel 68213 Applications:

1.   it can be applied to bulk grease;

2.   it can delivery the  0#~3#grease fluently;

3.   Use for lubrication system and grease diffluence set equipment.

4.   For dispensing grease of both short and long distance at high pressure.

It can be applied to industries like the gas station, the working line, the paper making, electricity, electron, port, construction machine, automobile, etc, is a perfect device for developing the mechanical quality.

Grease pump with barrel 68213 Buying direction:

It will be better to choose an excellent injector according to the viscosity and the article of the grease and the diameter of the drum. It can help you save your grease consumption also let the pump be more effective.

Grease pump with barrel 68213 Reference Picture:
