High power plasma cutting machine, double sides drive, track width is 6-9m, popular in shipyard, big machine factory etc, has precision cutting qualityTechnical data
Track Width mm(B), 7000, 8000, 8500, 9500
Track Length mm, As per customers
Machine Height mm(D), 1950
Machine Width mm(C), B+800
Torch Lifting Height mm, 200
Cutting Table Height mm, 450-520
Torch Height mm, 500
Main Voltage, 50Hz/380V
Output Power, 3500W
Positioning Speed mm/min, 6000
Allowed Torches, 4, 4, 5, 5
Working Width mm(A), 6200, 7200, 7700, 8700
Cutting Thickness mm, 6-160 for flame cutting, 1-70 for plasma cutting
Position of Drag Chain, As per customers
