Name Brand Surface Grinding Machine M618 (152*450)
2016-11-03 14:57  Views:300
Price:Negotiable
Model:M618
Send Inquiry

Advantage:
Compact structure, easy to operate. (Model M618 is a plain surface grinder designed by the company, featuring compact construction, littler area to cover, easilier to operate, and higher processing accuracy as well as the many merits of the small-size surface grinders as compared to those equipped with the table face in the same specifications. )
Light and flexible by using workbench longitudinal rolling guide.
Wear-proof, low resistance and long life, transversal guild ways with plastic-iron.
Easy to maintain( Grinding head is convinient to take down for maintenance. The V-type plane rail pairs with plastic overlay are applied to the guide rails between the saddle and the body and between the saddle and the bench, which are characterized in light and wear proof. The column's guide rail is designed in adjustable structure easily to maintain and repair. )

Operating Principle:
Table longitudinally, Saddle transversely traveling and Grinding head up and down movement.

Description



M618A

M618C

Width of the worktable

mm

15 2

15 2

Length of worktable

mm

450

450

T-slot

mm

1X14

1X14

Longitudinal travel

mm

45 0

45 0

Cross travel

mm

17 8       :

17 8       :

Vertical travel of grinding head

mm

  375

  375

Max. table load

kg

  150

  150

Distance from spindle center to table surface

mm

  370

  370

Spindle speed

r/min

  2850

  2850

Main motor power

kw

  1.1

  1.1

Grinding  W heel size( DXWXd)

mm

180x13x31.75

180x13x31.75

Coolant pump power

w

40

40

Overall dimensions: L x b x h

mm

1050x1100X1900mm

1050x1100X1900mm

Packing size(LXWXH)

mm

1100x1180X1950

1100x1180X1950

G/N weight

t

0.8  / 0.65

0.8  / 0.65
