Cement mill is one of the important cement grinding equipment, it is the key equipment of regrinding materials after the materials were broken. The cement mill plays an indispensable role in the cement production line and in the cement production process flow. It is widely used in the cement and silicate, newly building materials, refractory matter, chemical fertilizer, the dressing of black and non-ferrous metal, glass-ceramic and other industries. Cement mill has the characteristics of easy and safe to operate; stable to work; uniform product particle size; energy saving; low invest and high return; high efficiency.
Technical parameters of Cement Mill:
| Model | Capacity(t/h) | Mill pattern | Driving method | Power(kw) | Reducer | Weight(T) | Remark | |
| model | ratio | |||||||
| 2.2x7m | 8-9 | Open flow | Marginal | 380 | ZD70 | 5 | 54 | Without motor |
| 2.2x7.5m | 10-11 | Open flow | Marginal | 380 | ZD70 | 5 | 63 | |
| 2.2*8m | 10-12 | Open flow | Marginal | 380 | ZD70 | 5 | 65 | |
| 2.2*9.5m | 14-16 | Open flow | Marginal | 475 | ZD70 | 5 | 70 | |
| 2.4*10m | 19-19 | Open flow | Marginal | 630 | JR75 | 5.64 | 94.5 | |
| 2.4*11m | 19-21 | Open flow | Marginal | 630 | RZD80 | 6.3 | 99.2 | |
| 2.4*13m | 21-23 | Open flow | Marginal | 800 | MBY710 | 7.1 | 115.2 | |
| 2.6*13m | 28-32 | Open flow | Marginal | 1000 | MBY800 | 7.1 | 148 | |
| 2.6*13m | 28-32 | Open flow | Central | 1000 | MBY100 | 19.5 | 101.73 | |
| 3*12m | 32-35 | Open flow | Marginal | 1250 | MBY900 | 7.1 | 168.6 | |
| 3*13m | 34-37 | Open flow | Marginal | 1400 | MBY900 | 7.1 | 172.26 | |
| 3.2*13m | 45-50 | Open flow | Marginal | 1600 | MBY1000 | 7.1 | 196.26 | |
| 3.8*13m | 60-62 | Open flow | Marginal | 2500 | MFY250 | 16.5 | 204 | |
| 4.2*13m | 85-87 | Open flow | Marginal | 3530 | JQS3550 | 15.6 | 254 | |
If you have the need, please contact with us.
