Model:CX1212/1218
Send Inquiry
| CX Laser Die-board Cutting Machine(CX-1212/1218) | |
| Feature | |
| CX Die Cutting machine adopted two head bidirectional cutting technology is domestic and international pioneer.This technology become middle or samll power laser machine cutting deep moulding board to the true,this software can compatible for AUTOCAD,CoreDraw,Adobe Photoshop. | |
| Application | |
| * wooden plywood, plastic, organic material etc. commonly non-metal material all can cut*each die facture, machining industry. | |
| Main Data | |
| Type | CX-1212/CX-1218 |
| Laser power | 100W(bidirectional,it have two laser head) |
| Laser tube type | Co2 sealed laser tube,cooling water,10.6um |
| Cutting speed | 0-6000mm/min |
| Valid size | 1160*1200mm/1160*1800mm |
| Highest Cutting Thickness | 25mm |
| Sword seam breadth | 0.3-3mm(optional) |
| Color separation | Yes |
| Cutting precision | 0.02mm |
| Image form | PLT,EPS,BMP,DXF |
| Air feed means | Air or nitrogen gas |
| Power supply | 220V 10A |
| Shape size | 2900*1700*1200mm/3250*1700*1200mm |
| Packing | |
| Wooden case | |
| The working area and the laser power can be customized as requested. | |
