Spindle travel: 120mm
Max drilling capacity of auto-feeding: 1400mm(iron)
Table size: 1250*320mm
Table travel: Horizotal 600mm
Cross 300mm
Vertical 280mm
Feeding range of longitudinal, cross travel: (8step)22-555mm/min(1080mm/min)
Auto-feeding of Z-axis: 560mm
T-slot(number-width-distance): 3-14-95
Motor for repaid device of table(X, Y): 750W
Motor for vertical device of table(Z): 750W
Main motor: 1.5kw(vertical) 2.2kw(horizontal)
Overall dimension: 1700*1500*2200mm
N. W. /G. W: 1500/1600KG
