Grinding Capacity: LXBXH :500x250X330mm
Longitudinal table travel :520mm
Cross table travel :270mm
Spindle centerline to table :430mm
Safety load of bench ( in max ) 100kg      :
Table size :500x250mm
T-slot :12X1 mm X n
Bench speed :3-23m/min
Cross handwheel graduation :0.02mm
Cross handwheel per revolution :3mm
Wheel size(od x b x id) :200x16x31.75mm
Spindle size :2850r/min
Vertical fine adjustment graduation :0.005mm
Vertical per fine adjustment revolution :1mm
Spindle moter :1.1kw
Overall dimensions: L x b x h :1360x1190X1660mm
Packing case size :1300 X1220x1950mm
Net/Gross weight 1.1/1.2t
Compact structure are easy to operate . Longitudinal table travel on precision roller balls,light and flexile. Cross guide rail with turcite,wearable,vertical feed with fine adjustment to control the feed exactly.
