Table-Type Horizontal Boring Machine Bft 125/3 :

Year of manufacture: 1969
Manufacturer: Union
Condition: excellent working condition
Location: Ukraine

Technical details :
Working spindle diameter: 125 mm
Taper in spindle: metr. 80 mm
Max. diameter at facing work: 1400 mm
Max. diameter at boring without faceplate: 750 mm
Max. diameter at flange facing without faceplate: 1400 mm
Spindle stroke (W): 1120 mm
Faceplate diameter: 785 mm
Max. distance between center of working spindle and chucking area (Y): 1500 mm
Max. distance between faceplate and work rest: 3700 mm
Clamping table height: 970 mm
Longitudinal travel to working spindle (Z): 2000 mm
Cross motion (X): 1600 mm
Table surface: 1400 x 1600 mm
Table loading: 3 000 kg
Total installed power: 17,50 kwt
Overall dimensions: 7325 x 3500 x 4780 mm
Weight of machine: 30 800 kg

For more details please contact us.
