Production scale

Product Specification Brick/Board

Standard brick       240*115*53(mm)   26

Blind hole brick     240*115*90(mm)   12

Made up brick       390*190*190(mm) 4

Made up brick       390*240*190(mm) 3

Technical parameter

Host size        3800*2400*3100(mm)

Molding area 800*500(mm)

Molding height      50-240(mm)

Forming cycle       10-15(s)

Pallet size       810*520*25mm(Bamboo plastic)

Host weight   41.5KW

Power       10.2t

Technical features:

It is equipped with PLC automatic control systems,thus can realize the

human-machine communication,make logic control of safety in the appliances.

The vibration  mode is  classical, and suitable for producing high-strength blocks and standard bricks with short product-finished cycle and high efficiency.

The pressing and vibration combined organically. The finished products have high density and excellent performance

It is  multi-function and can produce various concreted products, hollow bricks, perforated bricks, standard bricks, insulated bricks, blind-hole bricks , pavement bricks, lawn bricks and so on only by changing its moulds, thus to satisfy all needs of the market, lower the investment risk greatly.

It makes full use of sand, stone powder, coal ash, slag,cinder and other industrial wastes  as raw materials, so the production cost is low.

The machine is excellent in performance, high in efficiency, and lower in energy

consumption .
