Model:ZH950
Send Inquiry
Lightweight, quiet generator is great for camping, picnics, or anywhere you'll need quick power. High-tech engine provides high output with less pollution (perfect for the outdoors).this portable generator is ideal for camping and powering small-scale household appliances like TVs or computers. 2-stroke, 63cc engine has recoil start and transistorized ignition. Meets EPA standards.
| MODEL: ZH950 | ||||
| Generator | Rated frequency (Hz): | 50 | 60 | |
| Rated voltage (V): | 230 | 120 | ||
| Rated output power (kW): | 0.65 | 0.70 | ||
| Max output power (kW): | 0.75 | 0.80 | ||
| Rated rotation speed (rpm): | 3000 | 3600 | ||
| DC output: | 12V 8A | |||
| Power factor cos: | 1.0 | |||
| Phase number : | Single phase | |||
| Noise level dB (A)/7m (zero load-full load): | 57 | |||
| Fule tank[L]: | 4 | |||
| Set | Overall dimensions [mm] ( L x W x H ): | 370x330x330 | ||
| N.W/G.W[Kg]: | 18/20 | |||
| Engine | Engine model: | ZH60 | ||
| Engine type: | 2-stroke | |||
| Displacement [cc]: | 63 | |||
| Compression ratio: | 8.5:1 | |||
| Rated power [(HP/rpm]: | 2.0/3600 | |||
| Rated rotation speed (rpm): | 3600 | |||
| T.C.I: | with | |||
| Spark plug: | F6RTC | |||
| Starting system: | recoil starter | |||
| Rotation direction (view from flywheel): | clockwise | |||
| Fuel type: | automotive unleaded gasoline | |||
| Lube oil brand: | SAE10W30 (above CC grade) | |||
| Low oil alarm system : | No | |||
