Mud pumps mainly have three models of F-1600, F-1300, F-1000 which are triplex single acting piston pumps. based on existed mud pumps domestic and abroad, we have made lots of improvements on lubricating cooling system, safe protection device and some drive components ensure the mud pumps advanced characteristics of premium structure, small volume, reliability and easy maintenance.

Mode: Triplex Single Acting Piston
Rated Power(KW/HP): 1176(1600)
Rated Strokes Per Minute: 120
Stroke Length(mm): 305
Gear Ratio: 4.206
Rated Rotating Speed(r/min): 438
Diameter of Suction Inlet(inch): 12
Diameter of Discharge Outlet: 5 1/2
External Size(L*W*H): 4.72*2.82*2.66
Weight(t): 25.21.
