Extruder designed by LEADER MACHINERY adopts big L/D and multi mixing structure, which is more suitable for the PE low temperature extrusion production.

Specially-designed spiral moulds for PE pipes, with inside oil controlling temperature system.

Beautiful and practical stainless steel body for the vacuum calibration and spray cooling system, unique multi-section vacuum system ensures the stable sizing and cooling for pipes; Special spray cooling system improves the cooling efficiency; Special water position, water temperature system make the machine more intelligent.

Hauling-off unit adopts particular pedrail structure, which is easy and convenient for operation; Pedrail clamping uses mechanical and pneumatic combining system, which is more reliable.

Cutting system adopts saw blades and planetary cutting means; Sumping uses hydraulic system, which ensures the smooth cross section; Equipped with dust-collecting unit, which ensures the clean working environment.

Main Technical data:
Model EMSG-65/30 EMSG-90/30 EMSG-120/30 EMSG-150/30 EMSG-120/33 EMSG-150/33
Pipe Size/mm D16-63 D75-160 D160-315 D200-450 D315-630 D400-800
Screw Diameter/mm 65 90 120 150 150 150
L/D 30: 1 30: 1 30: 1 33: 1 33: 1
Capacity/kg/h 80-160 180-220 250-400 500-600 700-900 800-1000
Hauling Speed/m/min 0-16 0-10 0-6 0-3 0-2 0-1.5
Cutting Means Saw blade or non-scrap cutting Planetary cutting Planetary cutting Planetary cutting Planetary cutting
