170F gasoline welding generator with welder

170F gasoline welder

Specification:

-----Welder:

Rated voltage (v): 26-28

No-load voltage (A): 65

Load voltage (V): 22-24

Max power (kw): 0.6

Adjusting amperage rang (A): 50-100

Diameter of welding rod (mm): 1.5-3.2

Load sustained rate: 60%

-----Engine:

Engine model: 170F

Engine type: 4-stroke, OHV 250, single cylinder, forced air-cooled

Borexstroke(mm): 70x54

Displacement (cm3): 208

Compression ratio: 8.2:1

Ignition system: Transistor magneto

Start system: Recoil start

Fuel tank capacity (L): 3.6

Oil capacity (L): 0.6

-----Generator:

Rated voltage (V): 230

Max.output (kw): 0.8

Rated output (kw): 0.5

Power factor: 1

Phase: Single phase

Working situation: Continue



190F gasoline welding generator with welder

190F gasoline welder

Specification:

-----Welder:

Rated voltage (v): 26-28

No-load voltage (A): 60-62

Load voltage (V): 22-28

Max power (kw): 4

Adjusting amperage rang (A): 50-200

Diameter of welding rod (mm): 2.0-5.0

Load sustained rate: 60%

-----Engine:

Engine model: 190F

Engine type: 4-stroke, OHV 250, single cylinder, forced air-cooled

Borexstroke(mm): 90*66

Displacement (cm3): 420

Compression ratio: 8.0:1

Ignition system: Transistor magneto

Start system: Recoil start

Fuel tank capacity (L): 25

Oil capacity (L):1.1

-----Generator:

Rated voltage (V): 120/230

Max.output (kw): 4

Rated output (kw): 3.5

Power factor: 1

Phase: Single phase

Working situation: Continue
