Technical data:
1) Size and output of major products:
A) Hollow blocks: 400X 200 X 200mm, 10PCS/mould
B) Perforated bricks: 240 X 115 X 90mm, 28PCS/mould
C) Solid bricks: 240 X 115 X 53mm, 52PCS/mould
D) Curbing: 1000 X 300 X 120mm, 2PCS/mould
2) Pallet size: 1100 X 950mm
3) Cycle time: 15 - 25 seconds
4) Type of major vibration: Table vibration
5) Vibration frequency: 2800 - 4500 times/minute
6) Total power: 45.38kW
7) Rating pressure: 21Mpa
8) Profile size (including pallet delivering device and green block delivering device): 7380 X 2100 X 3090mm
9) Weight: 11615kg.
