purified water filling line
The machine can also be used in hot filling if being installed with temperature controlling device. The handle of the machine can be freely and conveniently turned to adjust the machine to fill various types of bottles. The filling operation is faster and more stable because the micro pressure filling operation of the new type is adopted. There the output and benefit of the machine is higher than the machinery of the same specifications.
Characteristic:
1. It can carry out bottle washing filling and capping in one machine.
2. The whole machine designing is reasonable. The appearance is beautiful and the maintenance is convenient.
3. It adopts hanging type conveying-bottle structure to macke changing bottle model more convenient, faster and easier.
4. The main machine adopts advanced PLC control technology. The key electric elements are adopting international famous products.
Main Technical data:
| Model | CGF16/12/6 | CGF18/18/6 | CGF24/24/8 | CGF32/32/12 | CGF40/40/12 | CGF48/48/12 |
| Production Capacity:500ml(B/h) | 4000 | 6000 | 10000 | 14000 | 17000 | 20000 |
| Suitable Bottle Standard:(mm) | 150-300 | 150-340 | 150-340 | 150-340 | 150-340 | 150-340 |
| Suitable Cap Standard:(mm) | φ50-φ110 | |||||
| Filling Pressure:(Mpa) | 0.2-0.3 | |||||
| Installed Capacity:(L) | 3.13 | 3.84 | 3.84 | 5.6 | 6.3 | 7.3 |
| Filling Temperature: | Room Temperature | Room Temperature | Room Temperature | Room Temperature | Room Temperature | Room Temperature |
| Overall Size:L×W×H(mm) | 2400×1670 ×2350 | 2470×1970 ×2350 | 2865×2170 ×2350 | 3700×2570 ×2350 | 3800×2950 ×2400 | 4500×3400 ×2400 |
| Total Weight:(kg) | 2500 | 3000 | 4000 | 5000 | 6000 | 7000 |
