Model:BY-BZJ-300DS
Send Inquiry
H shape steel type pile drawer
Packaging: packaging with wooden
Delivery time: We can delivery the products in 1 week
Description:
Pile Extractor is designed for drawing out the steel H-pile from a diameter from 300mm to 500mm, with lifting capability of 300T.
Bacically, we have two styles of such pile extractor BY-BZJ-300DS and BY-BZJ-300LS. Both are operated by hydraulic pressure station with an wireless remote control, which can improve your working effciency greatly.
Specification:
Pile extractor performance
Rated working pressure: 35Mpa
Maximum flow: 160L/min
Rated pulling force: 300 t
Maximum clamping force: 260 t
Specifications for H-beam: 500mm-700mm
Product Feature:
