Model:HDX
SKYPE: HAIHANGCHINA
Main performance:
1. Touch screen, convenient adjustment
2. PLC controller,accurate calculation
3. Photoelectricdetection, great precision
4. The length isautomatic detected and set, without manual
5. Unlimited speed, the scope of speed and length are very widerange
6. Trilateralclosure H(pillow sealing)
7. Material of packingfilm: OPP
Features:
1. Automatic counting,feeding andpacking by double rows (2-200pcs/bag)
2.Option with one or two row counting, option with one or two rows packing
3. Cup counting and packaging is the twoindependent parts, can be operated alone.
4. Distance between withtwo cups only needs 2 mm
Optional Devices:
1.Code printer/ Thermal transfer printer
2.Fujiwheel: composite membrane: OPP,CPP,PE, etc
3. Lead aircraft: Devicefor punched and exhaust
4. Device for hanging hole (circular/butterfly hole)
5. Stainless steel
6. Others
Specification:
| Model | HDX-4500(DOU R) | HDX-6000(DOU R) |
| Option row | Single/Double | Single/Double |
| Packaging film thickness | 0.018-0.06mm | 0.018-0.06mm |
| Max. film width | 430mm | 550mm |
| Bag length | 150-750mm | 150-750mm |
| Cup diameter | 40-100mm | 40-100mm |
| Cup quantity | 10-200/pcs | 10-200/pcs |
| Packing speed(Depend on packing material) | 15-60Bag/min | 15-60Bag/min |
| Machine dimension | 5800×820×1250mm | 5800×1000×1300mm |
| Machine weight | 1200kg | 1300kg |
