1. Max. speed ofdriving belt: 120m/ min

2. Available carton size: Min.paperboard size is 260 * 720 mm,max paperboard size is 900 * 2040mm

3. Available paperboard thickness: 2 — 8mm. It applies to three or five layers corrugatedboard such as A,B,C、AB,ACand the like.

4.Available carton type: similar to NS0210 die cutting or slotted carton withfront and back straight.

5.Storable number of order: 500

6.Bale number: 5, 10, 15, 20, 25, 30

7.Gross power:17kw

8.Machine weight: 9.5t

9.Overall dimension of machine (length * width * height): 12 * 3.2 * 2. l m

10.Service environment: temperature ranges from 0 to40 °C and humidity30 %      to 90 % RH (without frosting).
