Model:YFX-2500F
Send Inquiry
| Model | YFX-2500F | |
| X-axis stroke | 600mm |
The stroke is subject to variation as per customer requirements |
| Y- axis stroke | 1200mm | |
| Z- axis stroke | 900mm | |
| A- axis | 0~360° | |
| A- axis rotary axis | Worm gear high precision indexing plate (with automatic clearance elimination device) | |
| Spindle speed | 50-8,000 revolution/min | |
| Spindle power | 7.5W | |
| Chuck diameter | 1,250mm(steel chuck) | |
| Machining diameter | 500~2500mm（25°~30°） | |
| Maximum load | 5000kg | |
| Weight of machine tool | 12000kg | |
| Boundary dimension of machine tool | 4200×2300×2700mm | |
