Model:Zp-m200
Parameters
| Model | Voltage(v) | Power(w) | Max static water head(m) | Max static water flow (L/H) | Size (mm) | Dimension of outlet(mm) | Net Weight(kg) |
| Zp-m200 | 12v | 4.8w | 1.6m | 200L/H | 43*38*30 | 8.5mm | 0.11kg |
| Zp-m300 | 12v | 4.8w | 1.5m | 300L/H | 47*42*31 | 13mm | 0.14kg |
Specification
| No. | Items | Specs |
| 1 | Driving method | Brushless, Permanent Magnetic |
| 2 | Pump material | ABS |
| 3 | Condition of use | Submersible |
| 4 | Fluids | Fresh and salt Water |
| 5 | Max working temp | 60 Celsius |
| 6 | Power consumption | 4.8w |
| 7 | Rated voltage | 12vdc |
| 8 | Max rated current | 0.4A |
| 9 | Noise | <35dB |
| 10 | Water proof class | IP68(submersible installed) |
| 11 | Life span | More than 30,000hrs |
| 12 | Power supply | Solar panel; DC electric source; Adapter; battery |
| 13 | Protection Function | Dry Run and blocking Protection (Optional) |
Features
- DC12V, low-voltage, safe, NO.1 aquarium submersible pump in china.
- 100% copper motor, brushless, non-pollution, electronic commutation, small size with high efficient ,long life span.
- super energy saving 50%.
- Small size, high efficiency, maintenance-free, low consumption, strong anti-jamming ability, stable performance.
- Adopt silicone foot to absorb vibration &reduce noise,easy for installation.
- Stator and control circuits are completely sealed by epoxy resin completely separated with rotor, waterproof, avoided water-leakage problem which long exists in normal DC motor pump products.
- Protection functions can be customized such as lock protection, dry-run protection and so on.
- Reduced the mortality to 0.05% after long-time study by R&D dep.
- Suitable for submersible installation.
- Offer ODM serve for pump and other controller system.
