Specification

overall weight(kg)

3400

L×W×H(mm)

4760×1600×2550

rated bucket capacity(m3)

0.6

Rated load(kg)

1200

     Maximum dump height (mm)

2750

Engine

              Model

 Changchai 4L68

              Type

In-line arrangement,

Water cooling, four-stroke

  Rated power(kw)

 37kw

Rated speed(r/min)

2200

Transmission    system

Model of torque converter

YJ240

               Type

single-phase single-stage radial-inward turbine triplex

Gearbox type

Fixed-spindle power shift

Gear shift

2 gears ahead,2 gear astern

  Hydraulic system

Distribution of work valve

ZL20B

Working pump

CBGj1045,CBGq1018

   Steering system

Type

Articulated hydraulic steering

 Max. turning angle

                                  27±1°

Min turning radius(mm)

3000

    Brake system

Brake type

Oil brake(Vacuum booster)

          Tyres

Standard tyres

1200-16

Optional wide tyres

12-16.5 or 14-17.5
