Model:GT 5/12
GT series HighEfficient straightening and Cutting Machines with Wide Range of cutting diameter,High Speed, High Precision , The highest straightening speed is 130 m/min, tolerance of linearity less than ±1 mm, diameter range from 3 mm to 16 mm.
| Performance | unit | Machine type | |||
| GT3/7 | GT5/12 | GT8/14 | GT10/16 | ||
| Dish round and cold rolled ribbed bars | mm | Φ3—Φ7 | Φ5—Φ12 | Φ8—Φ14 | Φ10—Φ16 |
| HRB400 hot rolled ribbed bars | mm | Φ3—Φ6 | Φ5—Φ10 | Φ8—Φ12 | Φ10—Φ16 |
| cut length | m | 0.8—6 | 1—12（It can be lengthened if necessary） | ||
| straightening speed（three grade ） | m/min | 60-80-110 | 70-100-130 | ||
| linear tolerance | mm/m | ≤ 2 | |||
| precision of cut length | mm | ≤ ±1 | |||
| power | Kw | 15 | 34 | ||
