Model:QGLM
QGLM Floor Shot Blasting Machine performs a mechanical process toremove surface contaminants, surface imperfections, or surface coating in acost effective and environmentally friendly method. This timesaving processstrips, cleans and profiles simultaneously for concrete, steel and asphaltsurfaces.
QGLM FloorShot Blasting Machine leaves the surfaceimmediately ready for the application of coatings or overlays, eliminatingdrying time and costly disposal procedures associated with other surfacepreparation methods. Industrial Floor Shot Blast CleaningMachine produces the highest bonding character of any surface preparationmethod.
QGLM FloorShot Blasting Machine system works using a high performance airless,centrifugal blast wheel for propelling blast media at a high velocity in acontrolled pattern and direction. Different surface profiles can be achieved byvarying shot size, shot flow rates and machine travel speed. Shot blasting is atime saving process that strips, cleans and profiles simultaneously.
Main Technical Specifications
| Model | QGLM200 | QGLM250 | QGLM550 | QGLM800 |
| Power | 14kw | 18kw | 29kw | 38kw |
| Effective cleaning width | 200mm | 250mm | 550mm | 800mm |
| Productivity on concrete | 80 m2/h | 120 m2/h | 300m2/h | 450 m2/h |
| Traveling speed | 0.5 – 23 m/min | 0.5 – 23 m/min | 0.5 – 25 m/min | 0.5 – 20 m/min |
| Dust collecting type | Blowback cartridge filters | Blowback cartridge filters | Blowback cartridge filters | Blowback cartridge filters |
| Travel type | Horizontal, self propelled | Horizontal, self propelled | Horizontal, self propelled | Horizontal, self propelled |
| Overall dimension | 1300×400×900mm | 1600×432×1016mm | 2050×720×1460mm | 2150×980×1450mm |
| Weight | 160kg | 335kg | 595kg | 770kg |
