Model:YH3202S
Send Inquiry
Feature
| 1. New design piezo printer, with high technology and favorable price. | ||||||||
| 2. Resolution is 1440DPI, printing speed can be 40m2/hour in 4pass. | ||||||||
| 3. Adopt DX5 head for printing, easy to operate, easy for maintance. | ||||||||
| 4. one machine for different business line. It can use eco solvent ink for bill board advertisment. It can use sublimation ink for textile industry. It can use water-based ink for photo imaging industry. | ||||||||
| 5. Equip Original maintop RIP software and yinghe control software. Can Optional photoprint software. | ||||||||
| 6. Equiped automatic cleaning system. | ||||||||
| 7. Equiped media take up driver, and midea release system. |
parameter
| Model | YH-3200S | |||||||
| Max media width | 33000mm | |||||||
| Max printing width | 3200mm | |||||||
| print head | 2pcs DX5 head (180nozzles x 8lines) | |||||||
| Resolution | 540 dpi, 720 dpi, 1440 dpi | |||||||
| print mode | 540x720dpi | |||||||
| 720x720dpi, 720x1080dpi | ||||||||
| 720x1440dpi, 1440x1440dpi | ||||||||
| print resolution | draft 2pass: 44m2/h | |||||||
| letter 4pass: 40m2/h | ||||||||
| image 6pass: 34m2/h | ||||||||
| photo 8pass: 24m2/h | ||||||||
| ink | water based ink, eco solvent ink | |||||||
| Capacity | 4 color, 440ccx2/color, 1000cc/color | |||||||
| Media | dye ink | PP paper, photo paper, backlit film, self-adhesive pp paper, cotton canvas, art canvas, etc. | ||||||
| sublimation ink | transfer paper, canvas, etc | |||||||
| eco solvent ink | flex banner, SAV vinyl, one way vision, mesh. | |||||||
| Media Cutting | Cutting in Y direction by cutter on the head | |||||||
| Media Heater | front and back heating | |||||||
| Media Take-up Device | Roll take-up device | |||||||
| Interface | USB | |||||||
| Power | AC 100 V - 120 V ± 10 %,AC 220 V - 240 V ± 10 %, 50 / 60 ± 1 Hz | |||||||
| Operation Environments | Temperature: 20°C ~ 35°C ,Humidity: 35%RH ~ 65%RH | |||||||
| Dimensions ( W x D x H ) | 4.45*0.95*1.46m | |||||||
| Weight | 800kg | |||||||
Photo detil
