Properties Units K300 Test Method
Construction & Composition --- Silicone & Ceramic filled ---
Color --- Light Blue Visual
Thickness Range mm 0.5~5.0 ---
Hardness Shore C 25 ASTM D2240
Density g/cc 2.7 ASTM D792
Tensile Strength KN/m 0.3 ASTM D412
Elongation % 64% ASTM D412
Continuous Use Temp C -40 to 150 EN344
Breakdown Voltage Kv/mm ≥5.0 ASTM D149
Volume Impedance ohm-cm 1.1*1016 ASTM D257
Dielectric Constant 1MHz 7.15 ASTM D150
Weight Daminify ---
Flame Rating --- V-0 UL 94
Thermal Conductivity W/m.k 3.0 ASTM E1461
UL, RoHS, REACH --- Compliance ---
Sheet sizes:
Standard sheet size:200*400mm；Custom Die-cut parts available；Available with or without PSA on reinforced side
