Model:PCL Series
PCL Vertical Shaft Impact Crusher
PCL Vertical Shaft Impact Crusher is widely used in metal and non-metallic ores, cement, refractory, bauxite, silicon carbide, artificial sand and finely, building materials, especially for the medium hard and super hard material .
Max. Feed Size: 60mm
Capacity: 20-380 t/h
Advantages:
- Deep cavity type rotor after optimization design, through material quantity increases by about 30%.
- High sand-making ratio; good size and shape.
- With functions of finely, coarse grinding.
- Week guard can use back up and down after partial wear, improve material utilization, can improve the service life 48% longer.
- Little affected by the material moisture content; water content up to 8% is available.
- “Stone hit stone”, “stone hit the iron” easy conversion; high efficiency and energy saving, high crushing ratio.
- Cube structure, high bulk density, and small iron contamination.
- Less wear of impeller from the lining, easy maintenance.
- Low wearing parts consumption – design of the best material impact angle of crushing cavity. Less friction between wear parts, 30% lower than conventional equipment running cost.
Technical data:
| Model | Max. feed size(mm) | Capacity (t/h) | Power (kw) | Rotation Speed |
| PCL-5545 | 30 | 20-60 | 30-45 (single motor) | 2258-2600 |
| PCL-7011 | 35 | 55-120 | 55-110 (single motor) | 1775-2050 |
| PCL-8526 | 50 | 113-240 | 150-264 (single/double motor) | 1460-1720 |
| S-10 | 60 | 220-380 | 320-500 (double motor) | 1242-1460 |
| S-12 | 60 | 300-380 | 500-630 ( double motor) | 850-1150 |
