B&W mode: B,M,2B,B/M,4B,C,PW, Power, Dir-Power, THI

Display: 15”LCD Full Touchscreen monitor

Transducer frequency: 2-11Mhz

Digital technology:

• Wide-angle imaging
• Panoramic focusing technology
• Compatible with high and low speed blood
• Rolling M technology
• Panoramic imaging
• Frequency composite
• Space compound
• Real-time Dynamic Aperture
• Tissue Harmonic Imaging

Scanning depth:  220mm

Smart touch-screen design      Supported

Cine-loop:     334 frame cine loop memory

USB ports:    2

Zoom:    Pan zoom for the active image

B-opt:    One-key Optimize

Multi language:  Supported

DICOM: DICOM3.0

Print:     Report print for text&graph&image

Measurement & Calculations

• B mode: Distance, angle, area, volume, trace length,distance ratio, area ratio, histogram
• M mode:    Distance, time, slope, Heart Rate

Software packages:  Abdomen, obstetric, Gynecology, Cadiac, Neural and Small Parts,Others

Transducer connector:    3 active transducer connector ports

Peripheral ports:   Video,2 USB ports,1 networking port,1 power inlet

Power supply:      100-240V~  50/60Hz  <100VA

Dimensions(main unit):358mm(W)*366mm(L)*65mm(H)  | Packing dimensions :415mm(W)*435mm(L)*140mm(H)

Net weight:  about 3.0kg | Gross weight: about 4.5kg
