Model:Heavy Duty 10 Ton Pneumatic Air Winch with Air Cylinder Brake
chinacoal03
Heavy Duty 10 Ton Pneumatic Air Winch with Air Cylinder Brake
Pneumatic winch with air cylinder brake , 10 ton air winch , 10 ton pneumatic winch
Heavy Duty 10 ton pneumatic air winch with air cylinder brake
JQHS100*20 series air winch adopts compressed air as power to drag heavy cargo. They are very popular with construction sites, platform of oilfield off-shore and inland; drilling platforms,marines,mining,engineering sites to load and unload heavy cargo.
Advantages
1.Passed ISO9001:2008, CE, CCS, API verification.
2. Reliable operation with little noise.
3. Variable speed.
4.Stable in inflammable, explosive, wet, damp and other extremely operating conditions.
5. Hand and foot double brake.
6. High starting torque ensures it starting with load.
7.Over-load protection.
Technical Parameters
| Item | Parameters | Unit | |
| Pressure of Compressed Air | 0.8 | MPa | |
| Rated Pull Force | 10 | Ton | |
| Rated Cable Speed | 20 | m/min | |
| Air Motor | Normal Power | 30 | kW |
| Diameter of Cylinder | 160 | mm | |
| Cylinder number | 5 | pcs | |
| Air Consumption | 0.4 | m3/s | |
| Drum | Diameter | 300 | mm |
| Width | 620 | mm | |
| Wheel Rim Diameter | 660 | mm | |
| Wire Rope Storage | 330 | m | |
| Wire Rope Diameter | 19 | mm | |
| Configuration | Length | 1638 | mm |
| Width | 960 | mm | |
| Height | 930 | mm | |
| Weight | 1300 | kg | |
