Technical Parameters

Communication Interface

USB Port

Laser Type

CO2 Gas

Tube Trigger Volt

20KV

Tube Operating Volt

15KV

Current

18~22mA

Engraving Area

12x8in.(30x20cm)

Maximum Item Size to Engrave

10.25W x 8.75L x 2.85H in.

Laser Tube (life hours)

1500-2000 Hours

Laser Power

40W

Engraving Speed

0-180mm/s  (0-7 in./s)

Cutting Speed

0-18mm/s (0-0.7 in./s)

Minimum Shaping Character

1 X 1mm (0.04 X0.04)in

Resolution Ratio

0.026mm / 0.001 in.  (1000dpi)

Power Supply

220V±10% 50HZ

Resetting Positioning

less than 0.01mm (0.0004 in.)

Motor Type

Stepper Motor

Software Supported

CORELLASER (CAN SUPPORT CORELDRAW DIRECTLY).

 It can support Window 7/8/vista/XP

Power Consumption

less than 250W

Operating Temperature

32-113F (0-45C)

Graphic Format Supported

PLT/DXF/BMP/JPG/GIF/PGN/TIF etc

Water Cooling

Water Pump include

Recommended Spare Parts/Consumables

Laser Tube, Focal lens, Reflection lens

Dimension OF this machine

96*66*50cm, and weight (included the plywood) is 56kgs.

machine spare parts

1×Air Pump(installed inside the machine) for Air Assist

(for blowing off debris as the laser engrave or cut)

1×Exhaust(installed inside the machine) with Tube ducts

( for extracting gases from the work area)

1×Water pump

1×USB Cable (connecting PC and laser)

1×DVD (Including software, User manual, Guiding videos etc.)

1×Power Cable

1×Tool box

EXW price

450USD/piece

Leading time

1-2days once receive your payment
