| Model | L23B | L25B | L28B | L30B | L33B | L36B |
| Swing Over Bed(mm) | 230 | 250 | 280 | 300 | 330 | 360 |
| Swing Over Gap(mm) | 430 | 476 | 502 | |||
| Swing Over cross side(mm) | 156 | 156 | 182 | 178 | ||
| Length of work piece(mm) | 550 | 550 | 660 | 714/914 | 750 | 1000 |
| Taper Of Spindle Bore | MT3# | MT4# | MT4# | MT5# | MT5# | MT5# |
| Spindle Bore(mm) | 20 | 26 | 26 | 38 | 38 | 38 |
| Spindle Speed(r/min) | 100-1800 | 125-2000 | 125-2000 | 60-1500 | 70-2000 | 70-2000 |
| Quill Diameter(mm) | 26 | 32 | 32 | 32 | 32 | 32 |
| Quill Travel(mm) | 40 | 65 | 65 | 95 | 95 | 95 |
| Main Motor Power(kw) | 0.55 | 0.75 | 0.75kw | 1.1kw | ||
| Net Weight(kg) | 95 | 150 | 180 | 460 | 490 | 520 |
| Floor Space Dimensions(mm) | 950×500 | 1250×750 | 1370×750 | 1480/1680×750×1420 |
