Model:300X3.2X2.2X30-12Z
Send Inquiry
TCT circular saw blades
- superior quality type
- Suitable for: Ripping and cross cutting without scoring saw blade
- Machine: table circular saw, panel sizing machine.
- Cutting Material: Hard bi-laminated board
- Advantage: Saw blades produced with long life tips for
- maximum wear resistance and extra-long life time.
- Made from top quality carbide and high-strength steel
- 1” standard arbor allows blade to fit other makes of saws, chop saws, tables, radial arm saws and more
- Application: Soft- and hardwood along and across grain, panel materials l Circular saws for
- construction work Design: Tungsten carbide tipped l Alternate top bevel tooth, positive hook angle
Specification:
| D | B | b | d | α | Z |
| 300 | 3.2 | 2.2 | 30 | 12 | 72 |
| 3.2 | 2.2 | 30 | 12 | 96 | |
| 350 | 3.5 | 2.5 | 30 | 12 | 72 |
| 4.4 | 3.4 | 30 | 12 | 72 | |
| 400 | 4.8 | 3.6 | 30 | 12 | 72 |
|
| 4.8 | 3.6 | 30 | 12 | 96 |
