KN)maximum test force

1000 /1200 /1500

testing space

(mm) upper and lower plate dimensions

Φ275

(mm) maximum distance of upper and lower  plate

300

(mm) distance between upright

285×130

measuring rang(kN) & minimum division value(kN/grid)

0～10

0.02

0～20

0.05

0～200

0.50

0～500

1.00

0～1000

2.00

1～1500

3.00

maximum magnitude for relative error of indicating value

±1.0%

maximum permissible value of relative variable of displaying value

1%

maximum permissible value of process and reverse relative error of displaying value

1.5%

Load keeps for 30 seconds, the variable of displaying value does not exceeds the largest testing force

0.5%

(mm)working Piston Travel

small Piston

large Piston

(mm) external dimension(L×W×H)

1120×800×1600
