Model:TDB
Send Inquiry
Features:
(1) Pile driving and pile extracting share the same guide rail, so TDB series pile driver combines two functions:pile driving and pile extracting in one.
(2) It can rotate freely and install posts at both sides, which is more convenient than other series.
| Model | Unit | TDB180 | TDB230 | TDB330 | |
| Pile Driver and Extractor | Hammer Rating | Joule | 400-500 | 600-800 | 900-1400 |
| Hammer Weight | Kg | 180 | 230 | 330 | |
| Blows per minute | Times | 350-780 | 600-900 | 500-735 | |
| Horse Power | HP | 22 | 24 | 32 | |
| Working Pressure | Mpa | 10-13 | 10-17 | 9-13 | |
| Oil Flow | L/min. | 30-55 | 36-65 | 45-65 | |
| Oil Tank Capacity | L | 100 | 100 | 120 | |
| Weight | Kg | 2600 | 2800 | 3100 | |
| Size (L*W*H) | Mm | 4300*2000*2600 | |||
| Pile Extracting Force | KN | 20 | 30 | 35 | |
| Pile Driller | Size (L*W*H) | Mm | 3200*350*250 | ||
| Weight | Kg | 300 | 310 | 320 | |
| Air Flow | m3/min. | 10 | 13 | 18 | |
| Diameter of Drilling Holes | Mm | 120 | 150 | 200 | |
| Max. Drilling Depth | Mm | 1700 | |||
| Working efficiency | mm/min. | about 250 | |||
Main components:
(1) multidirectional control valves and centralized hydraulic control rods
(2) Changchai brand diesel engine
(3) Rotary table
(4) Hydraulic hammers
(5) Hydraulic motor
