Technical specifications
Power of laser                                  10W / 20W/30W
Laser wavelength                             1064nm
Repeating frequency                        0-100KHZ
Beam quality                                     M<2
Marking range                                  30mm/30mm-300mm/300mm
Marking depth                                  ≤0.4mm
Marking line speed                           7000mm/s
Min.line width                                    0.01mm
Min.character                                    0.15mm
Repeatability accuracy                     ±0.002
Power supply                                    220V/50Hz
Power consumption                           400W / 600W
Weight                                               <60kg
Operating system                             Win98/Win2000/WinXP
Cooling mode                                   Built-in wind cooling
Control interface                               Standard USB
Laser type                                         Pulse or continuous
Laser wavelength                             1064nm
