SPECIFICATIONS
Cell: 156*156(mm)
No of cells and connections 60pcs
Weight 19.5kg
Dimension (L*W*H) 1640*990*50(mm)

CHARACTERISTICS
Model(-60P) HX210 / HX220 / HX230/ HX235/HX240/HX245/HX250

Maximum Power(Pm)
210Wp/220Wp/230Wp/235Wp/240Wp/245Wp/250Wp

Open circuit voltage(Voc)
34.80V/35.400V/36.00V/36.00V/36.30V/36.70V/36.90V

Optimum operating voltage(Vm)
29.00V/29.00V/29.50V/30.00V/30.00V/30.40V/30.90V

Short circuit current(Isc)
7.82A/8.19A/8.42A/8.46A/8.56A/8.63A/8.65A

Optimum operating current(Im) 7.24A/7.59A/7.80A/7.83A/8.00A/8.07A/8.09A

Maximum System Voltage at STC(Vm): 1000VDC

Operating temperature(oC): -40~ 85

5 years manufacturing warranty
10years warranty, 90% power output
25years warranty, 80% power output
