SPECIFICATIONS
Cell: 156*156(mm)
No of cells and connections 54pcs
Weight 18.0kg
Dimension (L*W*H) 1485*990*50(mm)

CHARACTERISTICS
Model(-54P) HX190 / HX195 / HX200/ HX205

Maximum Power(Pm)
190Wp/195Wp/200Wp/205Wp

Open circuit voltage(Voc)
30.80V/30.80V/31.00V/31.30V

Optimum operating voltage(Vm)
26.00V/26.00V/26.50V/26.50V

Short circuit current(Isc)
7.81A/7.95A/8.08A/8.28A

Optimum operating current(Im) 7.31A/7.50A/7.55A/7.74A

Maximum System Voltage at STC(Vm): 1000VDC

Operating temperature(oC): -40~ 85

5 years manufacturing warranty
10years warranty, 90% power output
25years warranty, 80% power output
