General Specifications
Rated Power 700W Rated Wind Speed 12 m/s
Rated Speed 415 rpm Cut in Wind Speed 3 m/s
Cut out Wind Speed 15 m/s (450 rpm) Survival Wind Speed 60 m/s
Dimensions/Weight
Rotor Diameter (A) 1.95 m
Rotor Height (B) 1.56 m
Tower Height
(Option) 2 - 6M height recommended
Total Height 1.60 m ( w/o Pole )
Turbine Weight about 70 kg
Rotor Specifications
External Darrieus 3 Blades
Internal Savonius 2 layers
Blades Material Anodized Aluminum
Axis Material Anodized Aluminum and Galvanized
Steel SS400
Generator Specifications
Generator Type AC, 3phase, Synchronism PMG
Rated Output 700W @ 12 m/s
Braking System
Automatic Over speed short circuit
braking system
Manual 3 Phase Short Circuit by Switch Brake.
Operation Conditions
Ambient Temperature -10~40?
Ambient Humidity 95? max.
